艾博康品牌EDLC 2.7V和3V超级电容器

2023-11-06 14:59:38

EDLC 2.7V和3V径向超级电容器

艾博康品牌EDLC 2.7V和3V超级电容器

EDLC 2.7V and 3V Radial Supercapacitors
High Energy and Power Density

Abracon’s Supercapacitors utilize the industry’s latest double layer technology to achieve high energy and power densities. With various combinations of these two characteristics, these supercapacitors can be utilized in applications requiring quick charge/dissipation or long lasting power output. Abracon’s Supercapacitors can operate in temperature ranges down to -40°C in situations where traditional batteries cannot. In addition, this product has a longer usage lifecycle and eliminates safety concerns seen in lithium batteries. These aspects make this product ideal for technical use cases such as uninterrupted power supply and backup power, micro energy storage, data transmission for LoRA/BLE/Zigbee and various energy start up designs. These technical use cases make Abracon’s Supercapacitors the ideal solution for wireless networks, energy harvesting, cold-crack engines, micro grid and much more.

Features:
Radial/Can package type
Nominal Voltage: 2.7V and 3V
High Power and Energy Densities
Low Resistance and High Peak Current Series
Wide Operating Temperature Range Series: -40°C to +85°C
Capacitance Range: 0.5F-30F
RoHS Compliant
Applications:Intelligent instrumentation,Lighting,Industrial Equipment,Power Tools,Wireless Networks IOT, IIOT, Ag IOT,Solid State Drive (SSD),Power Assist Circuits,Power Backup,Micro Energy Storage,Energy Harvesting,
DDR power backup


艾博康品牌EDLC 2.7V和3V超级电容器

高能量和功率密度
Abracon晶振的超级电容器利用行业最新的双层技术实现高能量和功率密度。凭借这两种特性的各种组合,这些超级电容器可以用于需要快速充电/耗散或长时间持续功率输出的应用中。Abracon石英晶振的超级电容器可以在低至-40°C的温度范围内工作,而传统电池则不能。此外,该产品具有更长的使用寿命,消除了锂电池的安全隐患。这些特点使该产品成为不间断电源和备用电源、微型储能、洛拉/BLE/Zigbee数据传输以及各种能源启动设计等技术应用的理想之选。这些技术使用案例使Abracon贴片晶振的超级电容器成为无线网络、能量采集、冷裂发动机、微电网等的理想解决方案。

特征:
径向/罐式包装类型
标称电压:2.7V和3V
高功率和能量密度
低电阻和高峰值电流系列
宽工作温度范围系列:-40℃至+85℃
电容范围:0.5F-30F
通过无铅认证
应用程序:智能仪器仪表,照明设备,工业设备,电动工具,无线网络IOT,IIOT,Ag IOT,固态硬盘(SSD),动力辅助电路,备用电源,微型能量存储,能量采集,DDR电源备份

Abracon的超级电容器可以在低至-40°C的温度范围内运行,而传统电池则不能。此外,该产品的使用寿命更长,消除了锂电池中的安全隐患。这些方面使该产品非常适合技术用例,如不间断电源和备用电源、微型储能、LoRA/BLE/Zigbee的数据传输和各种能源启动设计。

Series Name Type Nominal Voltage Capacitance Range Power Density @1F Energy Density @1F Inventory
ADCR-E02R7S Low ESR Radial 2.7 V 0.5 F - 10 F 5.93 kW/kg 1.58 Wh/kg Check Inventory
ADCR-T02R7S Wide Operating Temperature Radial 2.7 V 0.5 F - 25 F 2.93 kW/kg 1.14 Wh/kg Check Inventory
ADCR-S02R7S Standard Radial 2.7 V 0.5 F - 30 F 4.07 kW/kg 1.58 Wh/kg Check Inventory
ADCR-S03R0S Standard Radial 3.0 V 0.5 F - 30 F 3.53 kW/kg 1.37 Wh/kg Check Inventory
